Hanwha High Speed General Mounter DECAN L2
Specifications
- Alignment
- Fly Camera, Fix Camera
- Spindle & Speed
- 2 Gantry * 6 Spindle / 56,000 CPH
- Accuracy
- ±40µm Cpk≥1.0 (0402 (01005 inch) chip) /±30µm Cpk≥1.0 (IC, Stage Vision)
- Component Range
- Fly: 0402 ~ □21 mm / Fix: ~□42 mm (Standard) / ~□55 mm (MFOV) / ~ L75 mm Connector (MFOV)
- Dimension
- L 1,430 x D 1,740 x H 1,995
High-efficiency Modular Z:LEX YSM20WR Mounter placement machine
Specifications
| Model | YSM20WR |
|---|---|
| Applicable PCB | Dual lane Note 1 Same type PCBs: L810 x W356 to L50 x W50 Different type PCBs: up to L810 x W662 Note 2 Same type PCB: L810 x W280 to L50 x W500 Different type PCBs: up to L810 x W510 |
| Head / Applicable components | High-Speed Multi (HM) Head Note 3 0201mm to W55 x L100mm, Height 15mm or less Odd-shaped components (FM: Flexible Multi) head: 03015mm to W55 x L100mm, Height 28mm or less |
| Mounting capability (under optimum conditions as defined by Yamaha Motor) |
X axis 2-beam Note 1: High-speed multi-purpose (HM: High-speed Multi) head x 2 81,000CPH |
| Mounting accuracy | ±0.035mm (±0.025mm) Cpk≧1.0 (3σ) (under optimum conditions as defined by Yamaha Motor when standard evaluation materials are used) |
| Number of component Types | Fixed plate: Max. 140 types (conversion for 8mm tape feeder) Feeder carriage exchange: Max. 128 types (conversion for 8mm tape feeder) Trays for 30 types (Fixed type: max., when fitted with sATS30) and 10 types (Carriage type: max., when fitted with cATS10) |
| Power supply | 3-Phase AC 200/208/220/240/380/400/416V +/-10% 50/60Hz |
| Air supply source | 0.45MPa or more, in clean, dry state |
| External dimension (excluding projections) | L 1,374 x W 2,110 x H1,445mm (Main unit only) |
| Weight | Approx. 2,500kg (Main unit only) |
- Note 1 : When using conveyor separation specifications of 787mm between 1 to 4 lanes
- Note 2 : When using conveyor separation specifications of 630mm between 1 to 4 lanes
- Note 3 : Please contact us for info regarding mounting 0201mm components.
- Specifications and appearance are subject to change without prior notice.
JUKI Fast Smart Modular Mounter RS-1R placement pick and palce machine
Features
- Class leading speed, up to 47,000 cph
- Newly developed “Takumi Head” with changing recognition sensor height
- Optimum line balance and highest throughput
- Wide component range from 0201 (metric) to large connectors and ICs
- Optimal for LED placement
JUKI Fast Smart Modular Mounter RS-1XL placement pick and palce machine
Features
- Class leading speed, up to 42,000 cph
- 0201* ~ 74mm×74mm / 50mm×150mm
- Wide component range
- Optimum line balance and highest throughput
- Newly developed “Takumi Head” with changing recognition sensor height
- JUKI’s laser centering technology is fast, accurate and reliable for a wide range of parts.
JUKI High-Speed Chip Shooter KE-3010A placement pick and palce machine
Features
Continued Evolution of the KE Series
| Chip | 23,500CPH chip (Laser centering / Optimum) 18,500CPH (Laser centering / IPC9850) |
|---|---|
| IC | 9,000CPH (Vision centering / MNVC option) |
- From 0402(01005) to 33.5mm square components
- One multi-nozzle laser head (6 nozzles)
- The use of electronic double tape feeders enables mounting of a maximum of 160 component types.
- High-speed, on-the-fly vision centering
(When using both high-resolution camera and MNVC. (option)) - Longer sized PWB in X axis (option)
