SMT placement machine ASM Siemens placement machine TX2i/TX2/TX1
Introduction to ASM Siemens Mounter TX2i: ASM Siemens Mounter TX2i: Provide high performance and high precision in a very small footprint. The ASM Siemens Mounter TX2i mounter module sets a new benchmark for mass production. No other placement solution can achieve 25 µm @ 3 sigma accuracy at speeds up to 96,000 cph in such a small footprint (only 1m x 2.3m).
SMT placement machine Panasonic/Panasonic BM231 placement machine
SMT placement machine Samsung placement machine SM471Plus
High-performance chip shooter with a new fly camera
· World's highest speed of 78,000CPH among chip shooters of the same class
· With two gantry dual-lane construction, supports various production modes
-
Specifications
- Alignment
- Fly Camera
- Spindle & Speed
- 2 Gantry * 10 Spindle / 78,000 CPH
- Accuracy
- ±40μm@±3σ (Chip) / ±50μm@±3σ (QFP)
- Component Range
- 0402 ~ □14mm
- Dimension
- L 1,650 x D 1,690 x H 2,045
SMT placement machine Siemens ASM SIPLACE HS50 high-speed placement machine
SMT placement machine SIPLACE ASM Siemens D4/D3/D2/D1 high-speed placement machine
SMT Samsung Mounter SM481Plus 481
SMT Samsung Mounter SM482 Plus 482
SONY F209 PICK AND PLACE MOUNTER MACHINE
Sony G200BB pick and place machine MOUNTER
Super High Efficiency Dual Lane Modular YRM20DL Mounter placement machine
Specifications
Model | YRM20 | ||
---|---|---|---|
Super high-speed rotary RM head | High-speed general-purpose in-line HM head | Odd-shaped components in-line FM (flexible-multi) head | |
Nozzles (per 1 head unit) | 18 | 10 | 5 |
Applicable components | 0201mm to W12 x L12mm, Height 6.5mm or less | 0201mm to W55 x L100mm, Height 15mm or less | 03015mm to W55 x L100mm, Height 30mm or less |
Mounting capability (under optimum conditions) | 120,000CPH Note 1 | 100,000CPH Note 1 | 35,000CPH |
Mounting accuracy (under optimum conditions) | ±0.015mm Cpk≧1.0 Note 2 | ±0.035mm Cpk≧1.0 | |
Number of component types | Feeder carriage exchange : Max. 128 types = 32 feeders x 4 (conversion for 8mm tape feeder) Fixed plate : Max. 128 types (conversion for 8mm tape feeder), Trays : 60 types (maximum when equipped with eATS30 x 2) | ||
PCB dimensions | Single use : L50 x W50mm to L810 x W610mm Dual use : L50 x W50mm to L810 x W330mm | ||
Power supply | 3-Phase AC 200/208/220/240/380/400/416V +/-10% 50/60Hz | ||
Air supply source | 0.45MPa or more, in clean, dry state | ||
External dimension (excluding projections) | L1,374 x W2,102 x H1,445mm | ||
Weight | Approx. 2,550kg (Main unit only) |
Universal Instruments Genesis GC-120 Pick & Place Machine
GC120 Universal Instruments Pick & Place Machine Four 30-spindle rotary Lightning placement heads Dual on-the-head camera optics Spec Speed: 0.03 sec (120,000 cph) Range: 0402mm (01005) – 30mm x 30mm Vision capable of 217μm pitch bumped devices Max PCB Size: W350mm x L350mm (13.8″ x 13.8″) Feeder inputs: 144 (dual-lane 8mm tape) Feeder types: tape
