| Board size(with buffer unused) |
Min. L50 x W30mm to Max. L1,330 x W510mm (Standard L955) |
Min. L50 x W30mm to Max. L1,830 x W510mm (Standard L1,455) |
| Board size(with input or output buffer used) |
Min. L50 x W30mm to Max. L420 x W510mm |
- |
| Board size(with input and output buffers used) |
Min. L50 x W30mm to Max. L330 x W510mm |
Min. L50 x W30mm to Max. L540 x W510mm |
| Board thickness |
0.4 - 4.8mm |
0.4 - 4.8mm |
| Board flow direction |
Left to right (Std) |
Left to right (Std) |
| Board transfer speed |
Max 900mm/sec |
Max 900mm/sec |
| Placement speed (12 heads + 2 theta) Opt. Cond. |
0.08sec/CHIP (45,000CPH) |
0.08sec/CHIP (45,000CPH) |
| Placement accuracy A (μ+3σ) |
CHIP +/-0.040mm |
CHIP +/-0.040mm |
| Placement accuracy B (μ+3σ) |
IC +/-0.025mm |
IC +/-0.025mm |
| Placement angle |
+/-180 degrees |
+/-180 degrees |
| Z axis control / Theta axis control |
AC servo motor |
AC servo motor |
| Component height |
Max 30mm*1 (Pre-placed components: max 25mm) |
Max 30mm*1 (Pre-placed components: max 25mm) |
| Applicable components |
0201mm – 120x90mm, BGA, CSP, connector, etc. (Standard 01005 -) |
0201mm – 120x90mm, BGA, CSP, connector, etc. (Standard 01005 -) |
| Component package |
8 - 56mm tape (F1/F2 Feeders), 8 - 88mm tape (F3 Electric Feeders), stick, tray |
8 - 56mm tape (F1/F2 Feeders), 8 - 88mm tape (F3 Electric Feeders), stick, tray |
| Drawback check |
Vacuum check and vision check |
Vacuum check and vision check |
| Screen language |
English, Chinese, Korean, Japanese |
English, Chinese, Korean, Japanese |
| Board positioning |
Board grip unit, front reference, auto conveyor width adjustment |
Board grip unit, front reference, auto conveyor width adjustment |
| Component types |
Max 90 types (8mm tape), 45 lanes x 2 |
Max 180 types (8mm tape), 45 lanes x 4 |
| Transfer height |
900 +/- 20mm |
900 +/- 20mm |
| Machine dimensions, weight |
L1250xD1750xH1420mm, Approx. 1,200kg |
L1750xD1750xH1420mm, Approx. 1,500kg |
