Yamaha iPulse M20 high speed smt pick and place machine
Back to products
Fuji placement machine NXT II second generation M3/M6 PICK AND PLACE MACHINE MOUNTER

Fuji NXT I placement machine (m3/m6) mounter

Enquiry
Categories: ,
Description

Fuji NXT placement machine generation (m3/m6) technical parameters:

                                FUJI NXT I(m3/m6)
FUJI NXT I placement machine (m3/m6) PCB size: MIN：48mmx48mm                             MAX：510mmx534mm(double track)
FUJI NXT I placement machine(m3/m6)placement speed： H12HS:22,500；                  H08:10,500；                          H04:6,500；H01:4,200
FUJI NXT I placement machine(m3/m6) accuracy： H12S/H08/H04:0.05mm(3sigma) cpk≥1.00
FUJI NXT I placement machine(m3/m6)placement range： H12S:0402~7.5×7.5mm

HIGHT:MAX：3.0mm
H08: 0402~12x12mm                       H:MAX：6.5mm
H04: 1608~38x38mm                        H:MAX：13mm
H01/H02/OF: 1608~74x74mm(32X180mm)

H:MAX：25.4mm
G04: 0402~15.0mmx15.0mm                H:MAX 6.5mm
FEEDER： MAX：20 types/module (8mm tape conversion)
POWER SUPPLY： 3P/ 200V/ 10KVA
Air flow： 0.5MPa (5kgf/cm2),                    10NI/min.
MACHINE DIMENSION ： 2M II BASE：740(L) x 1934(W)
4M II BASE：1390(L) x 1934(W)
HIGHT： 1474 mm(M3 II)

1476 mm(M6 II/M6 IISP)
FUJI NXT I placement machine(m3/m6)WEIGHT： 1,350kg
